HVC-M04 Shiitake Mushroom Vertical Cultivation Container
Product image: images/mushroom/HVC-M04.jpg (Close-up of mushroom growth on the shelf)
I. Product Overview
The HVC-M04 is designed for the fruiting mode of shiitake mushroom spawn bags on tiered shelving systems, specifically addressing the combined requirements of temperature differential stimulation, light stimulation, and ventilation during both the color-changing and fruiting stages. The shelving units are customized according to the specific dimensions of the mushroom spawn bags and are paired with directional light strips to ensure uniform fruiting.
II. Core Competencies
● Programmable temperature variation stimulation: Simulates natural diurnal temperature fluctuations to promote primordia differentiation and ensure uniformity of mushroom buds.
● Targeted supplemental lighting: Interlayered light strips ensure uniform light distribution across the mushroom spawn bags, resulting in consistent coloration of the mushroom caps.
● High-density shelving: High loading capacity per unit area for菌棒 (mycelium sticks), with optimal cabinet utilization rate.
● Quick batch replacement: The shelving is pull-out, facilitating the entire batch's loading/unloading as well as inventory clearance and disinfection.
III. Typical Technical Specifications
project | parameter |
outline dimension | 12000 × 2438 × 2896 mm (40 feet) |
B菌棒装载量 | 3000–4500 rods (depending on specification) |
Temperature control range | 12–22 ℃（±1 ℃） |
relative humidity | 85%–92% RH |
beam | 0–800 lux (adjustable) |
rate of ventilation | 6–10 times per hour |
installed power | 11–15 kW |
source | 380 V / 50 Hz Three-phase |
IV. System Configuration
Specialized mesh rack systems for fungal spawn bags; variable-frequency refrigeration units; atomization humidification and floor wet film systems; adjustable LED light strips; integrated fresh air and exhaust ventilation system; ozone/UV disinfection interface; intelligent control cabinet.
V. Applicable Varieties
Shiitake mushrooms (including flower-shaped, thick, and smooth-meshed varieties), wood ear mushrooms, and other mushroom species cultivated using bag-based substrate cultivation methods.
VI.适用场景
Year-round shiitake mushroom production base; mushroom spawn bag manufacturing plant with accompanying fruiting chamber; Rural Revitalization Industrial Project.
VII. Delivery and Installation
Delivered as a complete shipment; power connection and commissioning will be completed within 3–5 working days after on-site hoisting and positioning; training on mushroom spawn bag shelving and fruiting management will be provided.
